Geiger counter schematic (reupload) Clipart
Signs & Symbols
· by Juhele
CC0 (Public Domain)
CC0 Public Domain - free for personal and commercial use, no attribution required.
License deed →
Geiger counter schematic (reupload) - Juhele (CC0 (Public Domain)), via Clipart.Free
Credit is optional - CC0 requires none.
About this image
Geiger counter schematic with simple explanation of Geiger-Müller tube operation.<br /> The file contains several layers - one all vector for simple exports, then other with drawing only and third with editable text fields so you can easily create translated versions.<br /> This revised version has fixed issues with text field so web PNG export should now work fine. Editable text layer is avail…
