Pull-down Resistor Circuit Schematic Clipart
Computer & Technology
· by AdamStanislav
CC0 (Public Domain)
CC0 Public Domain - free for personal and commercial use, no attribution required.
License deed →
Pull-down Resistor Circuit Schematic - AdamStanislav (CC0 (Public Domain)), via Clipart.Free
Credit is optional - CC0 requires none.
About this image
If the switch S1 is closed, electricity takes the path of the least resistance and flows from the positive terminal Vin through the 100Ω resistor R1 to the Input pin. If the switch is open, the Input pin is connected to the ground through the two resistors R1 and R2, so no electricity is floating toward the Input pin, as it would without the 10kΩ pull-down resistor R2, at least for some time afte…
| Dimensions | 615 × 890 px (SVG - scales to any size) |
|---|---|
| File size | 24.4 KB SVG · PNG 400/800/2000 px |
| License | CC0 (Public Domain) · Clipart licenses explained |
| Artist | AdamStanislav |
| Source | Openclipart · Original page → |
